概要

統合は車両のコストを下げるもっとも重要な手段です。ボディドメイン内の機能統合が広まっています。従来のBCM、シート、PEPS、TPMS、配電ボックス、ゲートウェイなどの機能は、集中的にコントロールされる傾向にありました。ゾーニングはドメイン横断的な統合設計の必然的な結果であり、ワイヤーハーネスを減らし、車両のコスト削減と効率向上に寄与できます。従来のBCM(ボディコントロールモジュール)は、BDC(ボディドメインコントローラー)やZCU(ゾーンコントロールユニット)へと進化しつつあります。

ゾーンコントロールユニット(ZCU)は、BDCをベースとし、物理的なゾーンに従って車両に接続されるデバイスです。現在、主に3つのモジュール、すなわち車両コントロールユニット(VCU)、熱管理システム(TMS)、ボディコントロールモジュール(BCM)を統合し、ゾーン内の電化製品の3つの機能、すなわち配電、通信ゲートウェイ、標準I/Oコントロールを可能にします。ゾーンアーキテクチャの核心的価値は、ソフトウェアとハードウェアを分離することにより、高度に統合された電子・電気接続と標準化されたサービス指向のインターフェースを実現し、ハードウェアプラットフォームの再使用と、より迅速で効率的な機能の更新とイテレーションを実現し、車両インテリジェンスの開発を加速することです。

OEM各社が計画しているセントラルコンピューティング+ゾーンコントロールアーキテクチャから見ると、ZCUは現在形になっていますが、量産化の進捗状況は大きく異なっています。Xpeng、GAC、Xiaomi、FAW Hongqi、Cheryなどは最新モデル用のZCUを量産しており、NIO、Neta Auto、Great Wall Motor、Volkswagen、BMW、Volvoなどの国外OEMは2024年~2026年にZCUを量産し、車両に搭載する予定です。

Changan AutomobileのSDVアーキテクチャ:このアーキテクチャは、C2(セントラルコンピューター)+EDC(エクスペリエンスコンピューター)で構成されるセントラルコンピューティングプラットフォームと、3つのVIU(車両統合ユニット)で構成されます。C2は最大508TOPSの演算能力を提供し、EDCは2,000GFLOPSのグラフィックス演算を提供し、分類され、集中化され、合理的に配置された完全な車両演算能力を実現します。

Changan Automobileによると、従来のBCMがBDCとVIUに進化するにつれて、統合レベルは徐々に向上し、統合範囲も従来のボディからパワー、シャーシ、熱管理、その他のドメインに拡大します。統合レベルが上がればI/Oの数も増えます。BCMからVIUまで、統合されたI/Oの数は100超から800超に増加し、複数のVIUに分割することで、1つのコントローラーのサイズを縮小することができます。

ZCUはコントロール機能を統合し、高性能MCUを搭載することで、MCUの分散を排除しています。

ゾーンアーキテクチャでは、ドメインゲートウェイはゾーンゲートウェイに進化し、ZCUはゾーンインフォメーションセンターとゲートウェイの一部の機能を担い、ゾーン内のサブモジュール間の通信管理と情報転送を担当します。ゾーンアーキテクチャは、各コントローラーをゲートウェイがコントロールするゾーンとして捉え、ゲートウェイは担当するコンポーネントの近くに配置され、各ゾーンゲートウェイはセントラルコンピューティングプラットフォームに接続されます。

ATECHの左右I/OコアVIU:VIUはサービス指向アーキテクチャ(SOA)に基づいており、従来のBCMの機能に加えて、空調熱管理、ゲートウェイ、窓の挟み込み防止機能を統合しています。比較的高い演算能力を持つドメインコントローラーが、CANゲートウェイとイーサネットゲートウェイの役割を担います。

ゾーンアーキテクチャでは、ZCUが複数のECU機能を統合します。複数の機能を実装するには、マルチコアMCUが必要になることが多いです。マルチコアMCUでは、各コアが単一の機能を実行できます。さらに、ZCUのマスターMCUには、より高い演算性能とストレージ容量、豊富なCAN/LINと高速自動車用イーサネット通信インターフェース、低消費電力インジケーターが求められます。

当レポートでは、中国のボディ(ゾーン)ドメインコントローラー・チップ産業について調査分析し、Tier 1サプライヤーの動向や、国内外のソリューションプロバイダーなどの情報を提供しています。

目次

第1章 ボディ(ゾーン)ドメインコントローラーの概要

  • ボディコントロール機能の開発経路
  • BDCの開発と進化
  • ZCUの主な機能
  • ボディ(ゾーン)ドメインコントローラー市場

第2章 Tier 1サプライヤーのボディ(ゾーン)ドメインコントローラーの概要と動向

  • Tier 1サプライヤーのボディ(ゾーン)ドメインコントローラーのサマリー
  • 動向のサマリー(1):ボディ(ゾーン)ドメインコントローラーと配電機能の統合
  • 動向のサマリー(2):ボディ(ゾーン)ドメイン統合ゲートウェイ
  • 動向のサマリー(3):ボディ(ゾーン)ドメインとパワードメイン、シャシードメインの統合

第3章 ボディ(ゾーン)ドメインコントローラーのチップ利用

  • MCU
  • MOSFET
  • HSDチップ
  • 通信チップ

第4章 OEMのボディ(ゾーン)ドメインコントローラーソリューション

  • ボディ(ゾーン)ドメインコントローラーOEMの搭載
  • Tesla
  • Li Auto
  • NIO
  • Xpeng
  • Leapmotor
  • Neta
  • Xiaomi
  • AITO
  • Changan
  • GAC
  • SAIC
  • Great Wall Motor
  • BYD
  • Geely
  • Voyah
  • FAW Hongqi
  • BMW
  • Volvo
  • Volkswagen

第5章 国外のボディ(ゾーン)ドメインコントローラーソリューションプロバイダー

  • Aptiv
  • Marelli
  • Continental
  • UAES

第6章 中国のボディ(ゾーン)ドメインコントローラーソリューションプロバイダー

  • Jingwei Hirain
  • Steelmate
  • YF Tech
  • Nobo Automotive Technology
  • KEBODA
  • OFILM
  • ATECH
  • FMT
  • Rothwell
  • Linked Intelligent Technology
  • Desay SV
  • G-Pulse
目次
Product Code: XX011

Research on body (zone) domain controller: an edge tool to reduce vehicle costs, and enable hardware integration + software SOA.

Integration is the most important means to lower vehicle costs. Function integration within the body domain has become widespread. Traditional BCM, seat, PEPS, TPMS, power distribution box, gateway and other functions tend to be controlled in a centralized way. Zoning is the inevitable result of cross-domain integration design, which can reduce wiring harnesses and help reduce vehicle costs and improve efficiency. Traditional BCM (body control module) is evolving towards BDC (body domain controller) and ZCU (zone control unit).

Zone control unit (ZCU) is a device based on BDC and connected to the vehicle according to the physical zone. At present, it mainly integrates three modules, i.e., vehicle control unit (VCU), thermal management system (TMS), and body control module (BCM), and enables three functions of electrical appliances in the zone, i.e., power distribution, communication gateway and standard I/O control. The core value of zonal architecture is to create highly integrated electronic and electrical connections and standardized and service-oriented interfaces by separating software and hardware, realize hardware platform reuse and faster and more efficient function updates and iterations, and accelerate the development of vehicle intelligence.

Seen from the central computing + zone control architecture planned by OEMs, their ZCUs now have taken shape, but their progress in mass production varies greatly. Xpeng, GAC, Xiaomi, FAW Hongqi and Chery among others have mass-produced ZCUs for their latest models, while NIO, Neta Auto, Great Wall Motor and foreign OEMs like Volkswagen, BMW and Volvo will mass-produce ZCUs and install them in vehicles during 2024-2026.

Changan's SDV architecture: the architecture consists of a central computing platform composed of C2 (central computer) + EDC (experience computer), and three vehicle integration units (VIUs). Wherein, C2 delivers computing power of up to 508TOPS, and EDC offers graphics compute of 2000GFLOPS, realizing classified, centralized and reasonably arranged full-vehicle computing power.

According to Changan, as traditional BCM evolves into BDC and VIU, the integration level is gradually improved and the integration scope is also expanded from traditional body to power, chassis, thermal management and other domains. The higher integration level makes the number of I/Os increase. From BCM to VIU, the number of I/Os integrated has increased from 100+ to 800+, and the size of a single controller can be reduced by dividing it into several VIUs.

ZCU integrates control functions and is equipped with a high-performance MCU, eliminating scattered MCUs.

Under zonal architecture, the domain gateway will evolve into a zonal gateway, and ZCU will take on some functions of the zone information center and gateway and be responsible for communication management and information forwarding between submodules in the zone. The zonal architecture takes each controller as a zone controlled by a gateway which is placed near the components it takes charge of, and each zonal gateway is connected to the central computing platform.

ATECH's left and right I/O core VIUs: VIU is based on service-oriented architecture (SOA) and integrates air conditioning thermal management, gateway and window anti-pinch functions in addition to functions of traditional BCM. The domain controllers with relatively high computing power will take on the role of CAN gateway and Ethernet gateway.

In zonal architecture, a ZCU will integrate multiple ECU functions. A multi-core MCU is often required to implement multiple functions. In the multi-core MCU, each core can run a single function. In addition, the master MCU in the ZCU will require higher computing performance and storage capacity, rich CAN/LIN and high-speed vehicle Ethernet communication interfaces, and lower power consumption indicators.

E3650, the ZCU MCU product of SemiDrive: In April 2024, SemiDrive launched a new-generation ZCU product family, coveting I/O-rich ZCU, control-integrated ZCU and compute-intensive ZCU and targeting core application scenarios such as body control, and body + chassis + power cross-domain integration. Wherein, E3650 is SemiDrive's flagship chip product designed for new-generation cross-domain integrated control ZCU applications.

Based on ASIL-D functional safety level, SemiDrive E3650 includes 4 ARM Cortex R52+ high-performance lock-step multi-core clusters. In terms of storage, it integrates 16MB embedded non-volatile memory with large-capacity SRAM. As for information security, it integrates Xuanwu Ultra Secure Hardware Security Module (HSM), and complies with the information security standards of ISO 21434, Evita Full and above, better meeting the needs of vehicle models going overseas. It uses the SSDPE (Super Speed Data Packet Engine), a hardware communication acceleration engine which achieves zero data packet loss when all CAN-FDs work simultaneously, effectively reducing CPU load and improving communication throughput. For low-power body application scenarios, E3650 can use a proprietary wake-up detection engine and a low-power CPU to reduce the overall static power consumption.

Infineon AURIX TC4x: TC4x microcontroller is designed by Infineon for ZCU and HPC applications. To satisfy the requirements of ZCU architecture and realize the multi-ECU integration of ZCU, Infineon Aurix TC4x microcontroller gets upgraded in terms of functional safety, information security, high-speed internal communication routing and core. The MCU contains 6 TriCore 1.8 embedded cores, and the clock frequency of each core can reach up to 500MHz.

As intelligent driving booms, foundation models require higher computing power. To this end, Infineon integrates a PPU (Parallel Processing Unit) in TC4x products to implement models that require massive data processing or fast execution time, for example, signal filtering, algorithm processing and model predictive control. With higher computing efficiency, the PPU undertakes complex signal processing and mathematical operations such as AI, motor control, and zone control, for Tricore cores which are mainly used for control. After integrating the PPU coprocessor, TC4x boasts computing power of 8000DMIPS+72GFLOPS*1, of which the PPU contributes 72GFLOPS.

At present, Infineon's Aurix TC4x microcontroller has been used to develop multiple ZCUs, including ZCU platforms of Tier1s like Continental, G-Pulse Electronics and Marelli.

Marelli ZCU: In April 2024, Marelli announced a zone control unit (ZCU) based on Infineon's AURIX TC4x microcontroller. Placed in specific zones of the vehicle and manage various functions, the ZCU consolidates electronic control units (ECUs) from multiple domains - including lighting, body, audio, power distribution, propulsion, thermal management, chassis control, and vehicle diagnostics. These solutions, combined with service-oriented software and cloud virtualization, enable customization of key vehicle performance through customized application software and functions.

ZCU integrates power distribution function and realizes intelligent power distribution via e-Fuse.

Under zonal architecture, the power distribution mode of vehicles will change from traditional fuse box power distribution to ZCU power distribution. ZCU integrates the surrounding electronic systems according to the physical location, with the integrated functions including BCM, power, chassis, thermal management and gateway. For the working voltages of the connected sensors and actuators are inconsistent, ZCU needs to be responsible for power supply and power management of electrical appliances in the zone to improve power efficiency and safety.

ZCU power supply adopts hierarchical distribution.

Under zonal architecture, zonal power supply generally adopts a hierarchical distribution method: 1. Primary distribution network (backbone power supply network) that requires dual power supplies (redundant backup) to transmit power from the backbone network to ZCUs; 2. Secondary distribution network where ZCU is responsible for further transmitting power downward to the underlying controller.

G-Pulse Electronics' power distribution solution based on "1+1+N" architecture: the architecture is composed of 1 central computing unit, 1 intelligent power distribution unit, and 4 ZCUs. Wherein, the intelligent power distribution unit includes primary power distribution, and can act as a separate power distribution controller, or integrate with the front zone control unit (FZCU) to form a primary and secondary power distribution solution, thus saving a primary power distribution unit. ZCUs are based on Infineon Aurix TC4x family, with different configurations required for customers' vehicle models.
