中国の乗用車用HUD産業（2024年）

China Passenger Car HUD Industry Report, 2024

出版日
ページ情報
英文 480 Pages
納期
即日から翌営業日
価格
価格表記: USDを日本円(税抜)に換算
本日の銀行送金レート: 1USD=144.06円
中国の乗用車用HUD産業（2024年）
出版日: 2024年06月22日
発行: ResearchInChina
ページ情報: 英文 480 Pages
納期: 即日から翌営業日
GIIご利用のメリット
  • 全表示
  • 概要
  • 目次
概要

HUD調査：AR-HUDが21.1％、LBSおよび光導波路ソリューションが量産間近。

自動車用ヘッドアップディスプレイシステム（HUD）は、光学の原理を利用し、車速、ナビゲーション、ADASなどの情報をリアルタイムで車両前方に表示します。表示画面によって、HUDは3つのタイプに分けられます。C-HUD、W-HUD、AR-HUDです。その中でもAR-HUD（ARヘッドアップディスプレイ）は、TFT、DLP、LCoS、LBSの技術経路を持っています。

1. 合計38の車種がAR-HUDを搭載し、そのうちVoyah Passionなどの11モデルがフルレンジで標準搭載されました。

2023年、AR-HUDは23万台を超える乗用車に搭載され、HUD市場全体の10.6%を占めました。2024年第1四半期には、HUD市場全体におけるAR-HUDのシェアが21.1%に急上昇し、主にXingyue L、Deepal S7、Deepal SL03、Lynk & Co 08の売上がそれを促進しました。

AR-HUD搭載モデル数は、2022年に17モデルに過ぎませんでしたが、2024年第1四半期には合計38モデルがAR-HUDを搭載しました。搭載率では、2024年第1四半期、AR-HUD搭載率上位10モデルはすべて中国の独立系ブランドで、中でも上位3モデルであるXingyue L、Deepal S7、NIO ES6の合計が全体の40％以上を占めました。

搭載率で見ると、2024年第1四半期にAR-HUDを標準装備したモデルは、Voyah Passion、Deepal S7、AITO M9、Zeekr Xなど11モデルありました。

Voyah Passionが搭載するAR-HUDは、ShenZhen QianHai Zinger Technologyが独占供給しています。この製品はTFT技術を採用し、最大60インチのディスプレイ、10°*3°のFOV、7.5メートルの撮像距離を提供します。この製品は、複雑な交差点案内や補助道路への進入を含む30種類以上の運転情報を表示でき、FCWなどのADAS情報も融合できます。

ZingerがVoyah Passionに供給したAR-HUDは、通常のフロントガラスでも使用でき、ゴーストの発生もありません。Zingerは10年にわたりHUDのコア技術の開発に専念しており、光路プリモジュレーション技術の特許を申請しています。さまざまな光学技術と構造設計により、OEMが「ウェッジフィルム」を除去し、通常のフロントガラスで撮像してゴーストを除去することを支援し、車両コストを削減します（従来のウェッジフィルムソリューションと比較して、ガラスコストを25％～30％削減）。また、4Sストアに便利なオプション設定とアフターメンテナンスをもたらし、アフターマーケットでの取り付けを可能にし、アフターマーケットHUDの普及を促進し、新たな機会をもたらします。

Zingerは2014年に設立され、深センに本社があります。2022年、Voyah Passionの独占AR-HUD供給プロジェクトを獲得しました。2023年、同社のAR-HUDは中国の大手新興自動車メーカー、ハイエンド新エネルギーブランド、新エネルギー自動車企業から指定されました。2024年により大きな市場シェアを獲得すると予測されます。

2. ARエンジンはAR-HUDのユーザーエクスペリエンスを向上させる主な要因です。

AR-HUDは、カメラ、レーダー、地図などのマルチエンドからの情報を統合し、レンダリングを用いて、低遅延、無歪曲、高精度でドライバーの前に映像を提示します。その製品特性上、AR-HUDソフトウェアには、どのような車両状況でも画像レンダリングの安定性を確保することが要求され、手ぶれ防止、歪み補正、空間座標表示など、ソフトウェアの光学アルゴリズムに高い要求があります。

現在、AR-HUD産業は一般的にソフトウェアとハードウェアを統合したソリューションを採用しており、光学デバイスのハードウェアとソフトウェアをバンドルしています。しかし、インテリジェントカーの急速なイテレーションが要求される中、ソフトウェアとハードウェアの分離の動向は避けられません。HMIの自己開発と迅速なイテレーションに対するOEMのニーズは、専門的なARエンジンの誕生を刺激します。

当レポートでは、中国の乗用車用HUD産業について調査分析し、開発動向、搭載数、利用状況などの情報を提供しています。
