ADASと自動運転のティア1調査レポート(2023年) 海外企業編

ADAS and Autonomous Driving Tier 1 Research Report, 2023 - Foreign Companies

出版日: | 発行: ResearchInChina | ページ情報: 英文 230 Pages | 納期: 即日から翌営業日

価格
価格表記: USDを日本円(税抜)に換算
本日の銀行送金レート: 1USD=151.08円
ADASと自動運転のティア1調査レポート(2023年) 海外企業編
出版日: 2023年07月05日
発行: ResearchInChina
ページ情報: 英文 230 Pages
納期: 即日から翌営業日
  • 全表示
  • 概要
  • 目次
概要

世界のADASと自動運転のティア1サプライヤーは完全なADAS/AD製品マトリクスを誇り、中国市場をつかむために継続的な努力を行っています。

ボッシュは、CMS以外のADAS/AD製品をフルラインナップしています。最新の製品としては、CES 2023で実物を展示した1550nmの長距離LiDARがあり、検出範囲は200m以上、消費電力は20W未満です。車内モニタリングシステム(IMS、OMS)は、OMSカメラをセンターコンソールのスクリーン上部に設置するか、車内ルームミラーと一体化した構成で、2024年に量産が開始される見込みです。

しかし、ソリューションの面では、現在、世界なティア1サプライヤーは、中国で注目されている運転駐車統合ソリューションをほとんど展開していません。その一例が、コンチネンタルのアンバレラCV3ベースのL2+ソリューションで、2021年1月に発表されましたが、生産が可能になるのは2026年です。

現在の受動的な立場に対処するため、世界のTier1サプライヤーも変化を模索しようとしています。例えば、ボッシュの運転駐車統合ソリューションであるWave3は、中国のXC部門とドイツの本社が同時に開発しており、そのうち中国のソリューションはデュアルOrin SoCを採用し、早ければ2023年に量産を開始する予定です。2023年6月、ZFは、意思決定時の部門間の内部摩擦を減らし、製品やソリューションの市場投入までの時間を短縮するため、乗用車シャシー技術とアクティブセーフティ技術の部門統合を発表しました。将来的には、アクティブセーフティがコックピットやシャシーなどすべての車両事業を統合した企業アーキテクチャを構築する可能性もあります。

2023年1月から5月までに、中国の新車乗用車に搭載された4Dレーダーは全体で6万5,500台で、そのうちフロントビューおよびリアビューレーダーは3万5,700台、コーナーレーダーは2万9,800台だっています。4Dレーダーの搭載が確認されたモデルは、ライジングオートR7、リーオートL7プロ、AITO M5などです。

技術的な観点から見ると、現在世界のティア1サプライヤーが採用しているCMSソリューションの主流は、2台のCMSカメラ+2台のOLEDディスプレイ、つまり左右のバックミラーを2台のバックミラーCMSカメラ(一般に広角カメラ)に置き換えるものです。3台のCMSカメラ+2台のOLEDディスプレイ+ストリーミングバックカメラ/センターコンソール・スクリーンという別のソリューションは、画像のステッチング/補正などの追加技術を伴うため、比較的少数の企業が採用しています。典型的なケースはMagna CLEARVIEWで、3台のCMSカメラ+ストリーミング・メディア・バックミラー・タイル型ディスプレイのソリューションを採用しています。注目すべきことに、Magnaは2017年に2台のCMSカメラ+2台のOLEDディスプレイのソリューションも提案したが、Magnaが実際に量産している製品は依然として現行の3CMSソリューションです。

自動車アーキテクチャのアップグレードに伴い、車内電子機器の主制御ユニットも数百のECUから数個のドメインコントローラーへと進化しています。次のクロスドメインコンピューティングプラットフォーム(例:コックピット-パーキング統合ドメインコントローラー、運転駐車統合ドメインコントローラー)は、自動車のコンピューティングニーズを満たすために使用されます。将来的には、中央コンピューティングプラットフォームがすべてのコンピューティングタスクを完了し、集中E/Eアーキテクチャを可能にするために使用されます。

現段階では、いくつかの世界なティア1サプライヤーが、2022年にマルチドメイン/セントラルコンピューティングプラットフォームソリューションをリリース/発表しています。これらはドメインコントローラー製品に代わる次世代ソリューションです。

当レポートでは、世界のADASと自動運転のティア1について調査し、市場の概要とともに、世界の規制、各社の製品およびソリューションの開発動向、および主要サプライヤーのプロファイルなどを提供しています。
