自動車用赤外線ナイトビジョンシステム:2023年
出版日: 2023年10月07日
発行: ResearchInChina
ページ情報: 英文 197 Pages
納期: 即日から翌営業日
  • 全表示
  • 概要
  • 目次
概要

ResearchInChinaのデータによると、2022年から2023年にかけての中国の新車乗用車へのNVS (ナイトビジョンシステム) 搭載台数は当初は増加し、その後は減少に転じました。2022年1月から7月までの搭載台数は1万3,300台で前年同期比141.9%増、2022年通年の搭載台数は2万4,400台で前年同期比37.0%増、2023年1-7月の搭載台数は1万3,400台で前年同期比0.7%増となり、搭載率は0.12%で2022年並みとなりました。

当レポートでは、自動車用赤外線ナイトビジョンシステムの市場を調査し、技術概要、産業チェーン、中国国内外の主要サプライヤーの製品比較、システムおよびカメラの導入数の推移・予測、価格帯・モデルなど各種区分別の詳細分析、主要サプライヤーの分析などをまとめています。

目次

第1章 自動車用赤外線ナイトビジョン技術

  • 赤外線熱画像装置の定義と動作原理
  • 赤外線検出器の定義・分類・パッケージング形態
  • 赤外線ナイトビジョン技術
    • ナイトビジョン技術の分類
    • アクティブ赤外線ナイトビジョン技術
    • パッシブ赤外線ナイトビジョン技術
  • 自動車用ナイトビジョン運転支援システムの定義
    • 車載用ナイトビジョン運転支援システムのメリット

第2章 自動車用赤外線ナイトビジョンシステムの産業チェーンと市場

  • 自動車用赤外線ナイトビジョン産業チェーン
    • 赤外線ナイトビジョンシステムの産業チェーン
    • 産業チェーンベンダーの分布
    • 中国国内外のナイトビジョンシステムサプライヤーの製品比較
    • 中国国内外の主要ナイトビジョンシステムサプライヤーの技術路線とターゲット市場
    • 中国国内外の主要サーマルイメージャーサプライヤー間の製品比較
  • 市場および技術の動向
  • 世界の自動車用ナイトビジョンシステム市場の規模
  • 中国の自動車用ナイトビジョンシステムの導入数
  • 中国の自動車用ナイトビジョンカメラの導入

第3章 OEMによるナイトビジョンシステムの導入

  • OEMによるナイトビジョンシステムの導入:概要
  • BMW
  • Benz
  • Audi
  • Cadillac
  • VW
  • BYD
  • Voyah
  • その他
    • Rolls-Royce
    • Bentley
    • DS
    • Peugeot
    • Hongqi
    • Porsche
    • Aion Hyper
    • Dongfeng Mengshi
    • HiPhi
    • DiDi
    • Dayun

第4章 自動車用赤外線ナイトビジョンシステムのサプライヤー

  • Magna
  • Xuanyuan iDrive
  • Guangzhou SAT Infrared Technology
  • Shenzhen Tianzhi Automotive Electronic Technology
  • Bright Way Vision
  • Baolong Technology
  • KYOCERA
  • Lambda Night Vision

第5章 自動車用赤外線ナイトビジョンデバイスのサプライヤー

  • Teledyne FLIR
  • AdaSky
  • Ophir
  • Stoneridge-Orlaco
  • Lynred
  • IRay Technology
  • Zhejiang Dali Technology
  • SEEK Thermal
目次
Product Code: YPX008

According to the data from ResearchInChina, during 2022-2023, the installations of NVS (night vision system) in new passenger cars in China went up at first and then down. From January to July 2022, the installations of NVS in new passenger cars in China was 13,300 sets, a like-on-like spurt of 141.9%; the full-year installations in 2022 reached up to 24,400 sets, jumping by 37.0% year on year; in the first seven months of 2023, the installations stood at 13,400 sets, up by 0.7% from the prior-year period, and the installation rate was 0.12%, on a par with 2022.

Automotive infrared night vision systems can be divided into active and passive types. Active infrared night vision is also called near-infrared night vision; passive infrared night vision falls into far-infrared night vision and low-light-level night vision.

Near-infrared night vision uses a powerful infrared emitter to illuminate the object during operation and images the object with the infrared rays reflected back from the object;

Low-light-level night vision amplifies a small amount of visible light received, and finally collects the image and projects it onto the corresponding display;

Far-infrared night vision mainly uses the infrared radiation emitted by the object itself for imaging. It is also called thermal imaging system, enabled by a thermal imager.

Infrared detector, an important upstream product in the industry chain, heads in the direction of small pixel size and low cost.

An infrared thermal imager is a product used to detect the infrared radiation from an object, and convert the temperature profile of the object into a video image after photoelectric conversion, electric signal processing and digital image processing.

The core components of a thermal imager include lens, detector, following circuit and image processing software. Wherein, the infrared detector, also known as infrared focal plane detector, is an important part of a far-infrared night vision system, and is heading in the direction of small pixel size and low cost.

The pixel size of uncooled infrared chips in the industry has been reduced from the initial 35μm to the current mainstream 12μm, and even 10μm and 8μm products have been unveiled or developed. The pixel size tends to be smaller;

The advantage of small pixel size is that the smaller pixel size allows for chip size reduction, lowers chip cost, and further meets the requirements for miniaturization and integration of thermal imaging modules.

In terms of infrared technology, Raytron Technology, iRay Technology's parent company, has expanded its 8μm product family, and has completed development of the prototype samples of the 1280×1024 new products; it has laid out the 10μm product family, and has trail-produced the 640×512 new products in small volume; in April 2023, it displayed IR-Pilot 1920X, its first automotive infrared thermal imager that packs an 8μm 1920×1080 infrared thermal imaging detector chip; in September 2023, it introduced an 8μm VGA (640×512) infrared thermal imaging detector chip. With these efforts, it promotes the development of global small-pixel infrared thermal imaging optics and image algorithms, facilitates the wide adoption of ultra-small pixel infrared focal plane detector chips in many new fields, and further cuts down the cost of automotive night vision systems.

Xuanyuan iDRIVE's infrared detector application history and planning: used imported 25μm detectors in 2015; used the self-developed 25μm detector in ceramic packaging in 2018, with little improvement in resolution; used 12μm detectors in wafer-level packaging in 2021, with the resolution increased to 640×512; plan to use 10μm wafer PLCC packaging in 2024, with two resolutions: VGA and SXGA. It shows that the size of detectors is getting smaller, the process is getting more mature, the resolution is getting higher and the cost is getting lower.

OEMs begin to integrate ADAS with infrared night vision technology.

Automotive night vision has begun to be integrated with ADAS. GAC Aion has adopted infrared sensing technology in its ADAS for the first time. The ADiGO Intelligent Driving System that integrates intelligent driving infrared sensing technology strengthens video capture and recognition capabilities in dark night, haze, and heavy rain environments. Combined with the existing LiDAR, radar and visible light camera, this system acts as an active driving assistance safety strategy that integrates night vision/thermal imaging. The integration of night vision with ADAS allows thermal imaging to output video signals that have clear outlines and are easy to recognize, and helps to transmit the data to ADAS as a supplement to the uploaded perception data of other environments. The development history is as follows:

In March 2022, GAC Aion announced that ADiGO will be equipped with intelligent infrared sensing technology;

In September 2022, Aion notified Xuanyuan iDRIVE of developing and trial-producing components and undertaking the task of manufacturing night vision cameras;

In July 2023, Aion Hyper GT, an ADAS-enabled production model integrated with infrared night vision technology, was available on market.

The subsequent extended applications of infrared night vision in ADAS also include intersection perception, multi-sensor data fusion, BEV spatial feature construction, image feature fusion perception, perceptual positioning and SLAM, stereo infrared, etc.

As concerns L4 autonomous driving, from Robotaxi nighttime road tests of Didi, AutoX, and WeRide, to DeepRoute.ai's announcement of entering nighttime intra-city freight, it can be seen that there is great demand for night driving in the autonomous driving field. And driving safety at night makes infrared sensors an indispensable part.

Starting from January 3, 2023, Didi has increased its Robotaxi service hour to 24 hours. Didi's autonomous vehicles with the latest software and hardware are equipped with a variety of sensors including visible light, LiDAR and infrared thermal imaging, which can recognize traffic lights and traffic signs up to 300 meters away, and enable stable recognition in backlight and night scenarios and also accurate recognition of minor obstacles.

Table of Contents

1 Automotive Infrared Night Vision Technologies

  • 1.1 Definition and Working Principle of Infrared Thermal Imager
  • 1.2 Definition, Classification and Packaging Forms of Infrared Detector
  • 1.3 Infrared Night Vision Technology
    • 1.3.1 Classification of Night Vision Technology
    • 1.3.2 Active Infrared Night Vision Technology
    • 1.3.3 Passive Infrared Night Vision Technology
  • 1.4 Definition of Automotive Night Vision Driving Assistance System
    • 1.4.1 Advantages of Automotive Night Vision Driving Assistance System

2 Automotive Infrared Night Vision System Industry Chain and Market

  • 2.1 Automotive Infrared Night Vision Industry Chain
    • 2.1.1 Infrared Night Vision System Industry Chain
    • 2.1.2 Layout of Industry Chain Vendors
    • 2.1.3 Product Comparison between Some Chinese and Foreign Night Vision System Suppliers
    • 2.1.4 Technology Routes and Target Markets of Major Night Vision System Suppliers Inside and Outside China
    • 2.1.5 Comparison of Products between Major Thermal Imager Suppliers Inside and Outside China (1)
    • 2.1.5 Comparison of Products between Major Thermal Imager Suppliers Inside and Outside China (2)
